Specifications
| Parameter | Specification |
|---|---|
| Processor | ADI SHARC 21489 |
| Sampling Rate / Bit Depth | 48K / 24-bit |
| Analog Input / Output Channels | 16 × 16 |
| Input Gain | 0/3/6/9/12/15/18/21/24/27/30/33/36/39/42/45/48 dBu |
| Phantom Power | +48V / 10mA max |
| Frequency Response | 20–20kHz ±0.5dB |
| Maximum Level | +18dBu |
| THD+N | < −94dB @17dBu |
| Input Dynamic Range | 113dB |
| Output Dynamic Range | 115dB |
| Channel Isolation @1kHz | 108dB |
| Input Impedance (Balanced) | 5.4KΩ |
| Output Impedance (Balanced) | 600Ω |
| System Delay | <3ms |
| Power Supply | AC110–240V, 50Hz/60Hz |
