Specifications
| Parameter | Specification |
|---|---|
| DSP Processing | TI 456MHz FLOPS DSP |
| Analog Channels | 8 inputs + 8 outputs |
| Dante Channels | 8 inputs + 8 outputs |
| Core Algorithms | Automatic mixing, automatic gain, noise cancellation, echo cancellation, feedback elimination |
| GPIO | Individual Inputs |
| RS485 | 1 |
| RJ45 Control Interface | 1 |
| Analog Max Gain | 51dB |
| Quantization Bits | 24-bit |
| Sampling Rate | 48kHz |
| Frequency Response (20–20kHz) | ±0.2dB |
| Analog-to-Digital Dynamic Range (A-weighted) | 114dB |
| Digital-to-Analog Dynamic Range (A-weighted) | 114dB |
| Input to Output Dynamic Range | 108dB |
| Total Harmonic Distortion + Noise | ≤0.003 @20–20kHz, 18dBu |
| Noise Floor (A-weighted) | -90dBu |
| Delay Storage | 2s |
| Analog Input to Analog Output System Delay | 3ms |
| Input Impedance (balanced) | 20KΩ |
| Output Impedance (balanced) | 100Ω |
| Max Input Level | +18dBu, balanced |
| Max Output Level | +18dBu, balanced |
| Equivalent Input Noise (20–20kHz, A-weighted) | ≤-110dBu |
| Phantom Power (per input) | 48V |
| Input Common Mode Rejection | 70dB @80Hz |
| Channel Isolation | 104dB @1kHz |
| Power Consumption | <24W |
| Operating Temperature | 0–40℃ |
| Operating Power Supply | DC12V/2A |
