| DSP Processing |
TI 456MHz FLOPS DSP |
| Analog Channels |
8 inputs + 8 outputs |
| Core Algorithms |
Automatic mixing, automatic gain, noise cancellation, echo cancellation, feedback elimination |
| GPIO |
Individual Inputs |
| RS485 |
1 |
| RJ45 Control Interface |
1 |
| Analog Max Gain |
51dB |
| Quantization Bits |
24-bit |
| Sampling Rate |
48kHz |
| Frequency Response |
20-20KHz±0.2dB |
| Analog-to-Digital Dynamic Range (A-weighted) |
113dB |
| Digital to-Analog Dynamic Range (A-weighted) |
113dB |
| Input to Output Dynamic Range |
108dB |
| Total Harmonic Distortion + Noise |
≤0.003 @20-20KHz, 18dBu |
| THD+N |
-95dB@17dBu |
| Analog Input to Analog Output System Delay |
3ms |
| Input Impedance (balanced) |
5.4KΩ |
| Output Impedance (balanced) |
600Ω |
| Max Input Level |
+18dBu, balanced |
| Max Output Level |
+18dBu, balanced |
| Equivalent Input Noise (20-20kHz, A-weighted) |
≤-110dBU |
| Phantom Power (per input) |
48V/10mA Max |
| Input Common Mode Rejection |
70dB @60Hz |
| Power Consumption |
< 24W |
| Operating Temperature |
0-40°C |
| Power Supply |
110V-240V AC 50/60Hz |
