8-Channel Pre-Amplifier

NAC-5001

  • Phantom Power
  • Status Indicators
  • Multiple Input Options
  • Priority and Chime Functions
  • Independent Volume Control

Description

Professional Multi-Channel Control

This pre-amplifier features a standard 1U aluminum alloy chassis with an integrated handle and rack-mount design, making it suitable for both rack and desktop installation. Its sleek, durable build ensures easy integration into professional setups.

Flexible Input Options

Equipped with 10 input channels, including 5 microphone (MIC) inputs, 3 standard AUX inputs, and 2 emergency (EMC) inputs, this device provides versatile audio source management for conferences, public announcements, and emergency broadcasts.

Independent Volume Adjustment

Each MIC and AUX channel has its own volume control, allowing precise sound balancing for different applications, from speech reinforcement to background music management.

Specifications

Parameter Specification
Power Supply AC 220V, 50Hz
Power Consumption ≤20W
Frequency Response 20Hz~20kHz
Signal-to-Noise Ratio (Mic Input) ≥50dB
Signal-to-Noise Ratio (Aux Input) ≥80dB
Tone Control (Bass) ±10dB at 100Hz
Tone Control (Treble) ±10dB at 10kHz
Total Harmonic Distortion (THD) ≤0.5% at 1kHz
Interface 1×TS Input Jack (Unbalanced), 4×TS&XLR Input Jack (Unbalanced), 3×Dual RCA AUX Input Jack, 2×Dual RCA Emergency Input Jack, 2×Dual RCA AUX Output Jack
