Corridor Speaker

NAC-2302H

  • Sturdy Structure
  • Clear & Bright Sound
  • Lightweight Installation

Description

The NAC-2302H indoor wall-mounted speaker boasts clear, vibrant sound, sturdy construction, and easy installation. It can be mounted on indoor walls or placed freely. Ideal for spaces like classrooms and corridors that require wall mounting. Featuring a 6.5-inch low-frequency paper cone speaker unit, it offers a rated power of 6W and a maximum power of 10W. Operating at 100V input voltage, it has a sensitivity of 92±2dB, delivering crisp audio across a frequency range of 150Hz to 15kHz. Its versatility and high-quality components make it a perfect choice for enhancing audio experiences in various settings.

Specifications


Parameter Specification
Power Supply AC220V / 1A @ 50Hz
Output Power 2×30W @ 8Ω
Input Sensitivity 0dBV
Frequency Response 150Hz–15kHz
Total Harmonic Distortion ≤0.5% (1kHz, @0dBV)
Audio Sampling Rate 48kHz
Signal-to-Noise Ratio ≥82dB
Ethernet 10M / 100M auto-adaptive
Trigger Input Short Circuit
Operating Temperature, Humidity -30°C to +55°C, ≤90%RH (non-frost)
Dimensions 275×185×120 mm
Product Net Weight 4 kg
Speaker Unit 6.5-inch woofer paper cone
Rated Power 6W
Maximum Power 10W
Input Voltage 100V
Sensitivity 92±2dB

Table listing device parameters and their specifications.
