Desktop Surveillance Microphone

TS-810A

  • Desktop Design
  • Professional Recording
  • Dynamic Noise Reduction
  • Acoustic Echo Cancellation
  • Versatile Integrations with IPC, NVR

Description

Desktop Surveillance Microphone

This desktop surveillance microphone features a durable aluminum alloy shell with oxidation and sandblast coating for corrosion resistance and a sleek look. It’s easy to install and blends well with indoor setups. Equipped with a DSP chip, it reduces ambient noise and ensures high-definition audio output. The mic supports wide-angle pickup and adjustable volume based on the environment, delivering clear sound without echo or reflection. Ideal for meeting rooms, security offices, and monitoring centers.

Specifications



Parameter Specification
Pick-up Range 1–3 meters (adjustable)
Frequency Response 20Hz to 20KHz
Sensitivity −45dB
Dynamic Range 95dB (@1KHz)
Signal Output Amplitude 2Vrms (@1KHz) / 5.6Vpp (@1KHz)
Output Impedance 600–1000 Ω (unbalanced)
Protection Circuit Power polarity reversal protection, ESD protection
Connection Method Supports three-wire, four-wire audio isolation output
Signal Transmission Distance 3000 meters (use shielded cable in complex electromagnetic environments)
Power Voltage DC 12V
Operating Environment Temperature −35℃ to 70℃
Casing Material Aluminum alloy, metal mesh
Dimensions 105×100×25 (mm)
Installation Method Desktop installation
