Specifications
| Parameter | Specification |
|---|---|
| Power Supply | AC 100V–240V 50/60Hz |
| Power Output | 240W×2 Channels (100V, 42Ω, rated output) |
| Frequency Response | 130Hz–18kHz (±3dB) |
| S/N (Signal to Noise Ratio) | ≥60dB |
| Working Temperature | −10 ~ 50°C |
| Dimensions | 483×435×100mm |
| Weight | 8.1kg |
| MIC 1–6 | −50dB (+48V phantom powered), XLR jack or φ6.3mm TRS jack |
| AUX1 | 500mV, 10kΩ, unbalanced, RCA jack |
| AUX2 | 1000mV, 10kΩ mixed monaural, unbalanced, φ3.5mm TRS jack |
| Speaker Output | 240W×2 Channels, 100V, screw terminal |
| AUX Output (Room) | 500mV, 600Ω, unbalanced, RCA jack |
| AUX Output (Outside) | 500mV, 600Ω, unbalanced, RCA jack |
| Phantom Power | ON/OFF switchable for MIC 1–6 (+48V) |
| MIC 1–6 EQ adjustment (low, mid, high) | MIC 1–6 effect controls (preset effect: plate / dome / delay / hall) |
| MIC 1–6 effect controls (room reverberation mode: L / M / S / OFF) | MIC 5–6 effect ON/OFF switch |
| ROOM speaker output ON/OFF switch | ROOM speaker EQ control ON/OFF switch |
| ROOM speaker volume control | OUTSIDE speaker output ON/OFF switch, OUTSIDE speaker EQ control ON/OFF switch, OUTSIDE speaker effect ON/OFF switch, OUTSIDE speaker volume control |
Table listing device parameters and their specifications.
