IP Intercom Panel

NAS-8516

  • Offline Intercom
  • Pre-set up to 9 terminals
  • Broadcast Announcements
  • Full-duplex Communication

Description

IP Intercom Panel

This IP Intercom Panel is a reliable terminal for IP intercom systems. It features a sleek black plastic shell, built-in 3W speaker, and microphone for clear hands-free communication. Supports server-free operation with offline intercom and broadcasting. Easily preset up to 9 terminals for one-touch calls or 9 zones for quick paging. Ideal for schools, offices, factories, and other indoor environments requiring fast, stable, and cost-effective voice communication.



Specifications

Parameter Specification
Power Supply DC12V/1.5A
Power Consumption ≤5W
Network Communication Protocol TCP/IP, UDP, SIP, ARP, ICMP, IGMP
Network Chip Rate 10/100Mbps
Audio Sampling Rate, Bit Rate 8kHz to 22.050kHz, 16bit, 16kbps to 352kbps
Signal-to-Noise Ratio, Frequency Response >80dB, 25Hz to 10kHz
Interfaces Alarm Signal Input, Alarm Signal Output, Network Interface, Power Interface, Audio Output, Microphone Input
Operating Temperature, Humidity 0°C to 45°C, ≤90%RH (non-condensing)
