| Parameter |
Specifications |
| Power Supply |
DC 24V/2.7A |
| Amplifier Power Output |
2×20W/8Ω |
| Network Protocol |
SIP 2.0 (RFC 3261), HTTP, TCP/IP, UDP, ARP, ICMP, IGMP |
| Audio Sampling Rate |
8kHz-44.1kHz, 16bit |
| Transmission Bit Rate |
8kbps-320kbps |
| Video Transmission Bit Rate |
512Kbps-4Mbps |
| Video Coding |
VGA/720/1080P |
| S/N (Signal-to-Noise) Ratio |
≥80dB |
| Frequency Response |
100Hz-20KHz(MP3) |
| Interface |
1×RJ45 Ethernet Port, 2×Relay Input, 1×Relay Output, 2×Line Input, 1×Line Output, 2×Speaker Output (8Ω/20W), 1×Power Input |
| IP Rating |
IPX5 |
| Gross Weight |
4.9kg |
