| Camera |
| Model |
4x5MP AI Multi-directional Network Camera |
| Image Sensor |
4×1/2.8″ Progressive Scan CMOS |
| Min. Illumination |
Color: 0.005Lux@F1.6
B/W: 0Lux with IR on |
| WDR |
120dB Super WDR |
| Shutter Time |
1/100000s~1s |
| Day/Night Mode |
Day/Night/Auto/Customize/Schedule |
| DORI Distance |
D:66m ~ 154m/ O:26m ~ 60.5m
R:13m ~ 30m/ I:6.5m |
| IR Wave Length |
850nm |
| IR Distance |
30m |
| S/N |
>55dB |
| Lens |
| Lens |
Motorized 3mm~9mm @F1.6 |
| Mount |
φ14 |
| Field of View |
H92° ~ H40°/ D116° ~ D49°/ V67°~V30° |
| Focus Control |
Remote |
| Aperture |
F1.6-F2.7 |
| Iris Control |
Fixed |
| Camera Angle Adjustment |
Pan ±120°, Tilt +15 to +105°, Rotation ±90°, Twist ±30° |
| Video |
| Max. Image Resolution |
2592×1944 (5MP)x4 |
| Primary Stream |
60Hz: 30fps@(2592×1944, 2592×1520, 2048×1536, 1920×1080, 1280×960, 1280×720)
50Hz: 25fps@(2592×1944, 2592×1520, 2048×1536, 1920×1080, 1280×960, 1280×720) |
| Secondary Stream |
60Hz: 30fps@(1280×720, 704×576, 640×480, 640×360, 352×288, 320×240)
50Hz: 25fps@(1280×720, 704×576, 640×480, 640×360, 352×288, 320×240) |
| Bundle Stream |
60Hz: 30fps@(1920×1080, 1280×960, 1280×720)
50Hz: 25fps@(1920×1080, 1280×960, 1280×720) |
| Video Compression |
H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Video Bit Rate |
16Kbps~16Mbps(CBR/VBR Adjustable) |
| Web Access |
Support Chrome/Microsoft Edge/Safari/Firefox/Browser |
| Image |
| Privacy Masking |
Up to 4×8 areas |
| ROI |
Up to 4×8 areas |
| Image Setting |
Brightness/Contrast/Saturation/Sharpness |
| Image Enhancement |
BLC, HLC, 2D DNR, 3D DNR, AGC, AWB, Deblur, Anti-flicker, Corridor Mode |
| Interface |
| Ethernet |
1*RJ45 10M/100M/1000M Ethernet Port |
| Alarm I/O |
1/1 |
| Audio I/O |
1/1 |
| Network |
| Network Storage |
NAS(Support NFS, SMB/CIFS), ANR |
| Protocol |
IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2 |
| Wireless Network |
| WLAN |
802.11n/802.11g(For Installation and Commissioning) |
| Audio |
| Audio Compression |
G.711/AAC/G.722/G.726 |
| Audio Sampling Rate |
8/16/32/44.1/48KHz |
| Audio Bit Rate |
16~256kbps |
| Intelligent Analytics |
| Video Analysis |
Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed |
| Target Classification |
Human, Motor Vehicle(Car, Motorcycle, Bus, Truck), Non-motor Vehicle (Scooter) |
| Event |
| Basic Event |
Motion Detection, Network Disconnection, Audio Alarm, External Output, etc. |
| Exception |
Network Disconnection, IP Address Filtering, Record Failed, SD Card Full, SD Card Uninitialized, SD Card Error, No SD Card, Watermark |
| Event Action |
FTP Upload, SMTP Upload, SD Card Record, SIP Phone, HTTP Notification, etc. |
| System |
| Storage |
Supports 2 microSD/SDHC/SDXC cards for local storage, each with a maximum capacity of 1TB |
| SIP/VoIP Support |
Support |
| System Compatibility |
ONVIF Profile G & S & T & M, API |
| General |
| Working Temperature |
-40℃~60℃ |
| Working Humidity |
0~95%(Non-condensing) |
| Power Supply |
PoE(802.3at)/ DC 12V±20% |
| Power Consumption |
Min: 8.8W (DC 12V), 10W (PoE)
Max: 26.5W (DC 12V), 22.4W (PoE) |
| Surge Protection |
4KV |
| Weather Proof |
Up to IP66-rated for Weather-resistant Performance |
| Housing |
Vandal-proof IK10-rated Metal Housing |
| Weight |
3.1kg(Only camera), 3.8kg(With package) |
| Dimensions |
φ280mmX97mm |
| Warranty |
3/5 Years |
| Certifications |
| EMC |
CE-EMC (EN 55032, EN 55035), RCM(AS/NZS CISPR 32), FCC (PART 15B) |
| RF |
CE-RED (EN 300 328, EN301489-1, EN301489-17, EN 62133), FCC(Part 15.247), RCM(AS/NZS 4268) |
| Safety |
CE-LVD (EN IEC 62368-1) |
| Environment |
CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU) |
| Protection |
IP66, IK10 |
