AI Road Traffic Supplement Light Pro Bullet Plus Camera

TS8266-X4RIWG1

  • Integrated Supplement Light
  • Traffic Violation Detection
  • Intelligent AI-powered LPR Algorithm
  • Traffic Flow Statistics
  • Evidence Camera Linkage
  • 4X(8~32mm) AF Lens
  • 1/8” Sensor & 0.05Lux Starlight
  • 60fps High Frame Rate

Description

Sharper Insights for Smarter Roads

maxresdefault
maxresdefault
maxresdefault
maxresdefault
Introduction VideoUnboxing VideoIR LED Supplement Light DemoWhite LED Supplement Light Demo

Integrated Supplement Light

Integrated with supplement light of IR LED Light, AI Road Traffic Supplement Light Pro Bullet Plus Camera could turn on and off the supplement light, and change the luminance of the supplement lighting automatically, achieving a flexible way for the monitoring control.

Traffic Violation Detection

Accurately detect and alert violation events such as No-plate Vehicle Detection, Specific Lane Detection, Reverse Driving Detection, Allowlist/Blocklist Detection and Vehicle Event Detection for mission-critical road traffic management.

traffic violation detection

Intelligent AI-powered LPR Algorithm

Based on AI algorithm, the LPR function provides value-added data via a pre-trained deep learning model and continuously training to algorithms automatically. Milesight AI Road Traffic Camera can not only recognize vehicle plates in real time, but also identify various vehicle features, like vehicle type, brand, color, etc., generating reliable traffic insights to improve safety and mobility.

Traffic Flow Statistics

The vehicle counting result based on vehicle type and various vehicle features can be shown intuitively in camera’s live view and the camera can also generate useful report insights to further enhance traffic management capabilities.

traffic flow statistics

Evidence Camera Linkage

Beyond vehicle feature and license plate recognition, Milesight AI Road Traffic Camera can link with any regular cameras to capture the evidence. With seamless triggering between Milesight traffic camera and regular camera, users can easily provide solid and convincible evidence including LPR results as well as overview snapshots.

evidence camera linkage

LPR Smart Search

Relevant videos can be found quickly by searching for only a portion of the target suspect vehicle’s features, such as vehicle brand, type & color, plate color, plate number, direction and etc., ensuring efficient event investigations and intelligent road traffic monitoring. It also supports manual export and auto export for easy management.

lpr smart search

Plate Data Management

A number of options to ensure the powerful plate data management and flexible deployment of Milesight traffic systems.

On-edge Plate Management

Standalone Allowlist/Blocklist list management realizes the fast implementation for barrier control.

Milesight Back-ends Integration

Work well with Milesight own back-ends including Milesight NVR, CMS and Milesight VMS Enterprise to form fully closed-loop traffic solutions.

Third-party VMS Integration

Various CGI/APIs and interfaces, protocols like TCP, HTTP make it easy to integrate with all data being pushed to third-party VMS or platforms.

plate data management

1/8” Starlight Sensor & 0.05Lux Ultra Low Light

Milesight AI Road Traffic Camera, with top-notch STARVIS Starlight Sensor, can provide detailed clear images in low and near-infrared light conditions down to 0.05Lux (Color) and 0Lux (B/W), ensuring good performance for 24/7 traffic monitoring.

starlight sensor 2

By Conventional Camera
By Milesight Camera

60fps High Frame Rate

With the industry leading frame rate reaching 60fps, Milesight AI Road Traffic Camera can easily catch vehicle and plate images with no latency despite of the high-speed movement.

versatile interfaces

Versatile Interfaces

A rich set of interfaces such as DC, Audio I/O and Alarm I/O are available to offer more choices for easy management and various needs. For example, the alarm interface allows easy integration with traffic light control systems, ensuring smooth operation and compatibility.

SIP/VoIP Support

Milesight AI Camera features industry leading SIP/VoIP function and video streaming for mobile phones and video phones.

Specifications

Camera
Name AI Road Traffic Supplement Light Pro Bullet Plus Camera
Image Sensor 1/1.8″ Progressive Scan CMOS
Min. Illumination Color: 0.009Lux@F1.6
B/W: 0Lux with IR on
Shutter Time 1/100000s~1s
Day/Night Mode Day/Night/Auto/Schedule
S/N >55dB
Lens
Lens 8~32mm, 4X Optical Zoom
Field of View H44°~H13°/D51°~D15°/V25°~V7°
Mount Φ14
Focus Control Auto/Manual
Aperture F1.6~F1.7
P-Iris Support
Iris Control Auto
Road Traffic Management
Max. Vehicle Speed 120km/h
Capture Rate 0.99
Recognition Accuracy 0.98
Coverage 3 lanes
Country Region Supported More than 80 countries and regions
ANPR Distance Up to 50m
Attributes Identification Plate Color, Vehicle Type, Vehicle Color, Vehicle Brand, No-plate Vehicle Capture, Vehicle Direction Detection
* Vehicle Color and Plate Color identification are not supported in low-light or night conditions.
Smart Traffic Function Evidence Camera Linkage, Specific Lane Management, Vehicle Classification & Counting
White/Black List Up to 20,000 records inside the camera
LPR Smart Search Support
Illuminator
Supplement Light IR LED
IR Wave Length 850nm
Light Bead 12
Illumination Distance Up to 60 m
Light Control Auto/Customize
Interface
Ethernet 1*RJ45 10M/100M Ethernet Port
Audio I/O 1/1
Alarm Input 2
Alarm Output 2 (1 relay output; 1 open collector output, max. 12V DC/10mA)
Wiegand 1
RS485 1
Video
Max. Image Resolution 3840×2160
Primary Stream 60Hz: 60fps@(3840×2160, 3072×2048, 2592×1944, 2592×1520, 2048×1536, 1920×1080, 1280×960, 1280×720)
50Hz: 50fps@(3840×2160, 3072×2048, 2592×1944, 2592×1520, 2048×1536, 1920×1080, 1280×960, 1280×720)
Secondary Stream 60Hz: 60fps@(704×576, 640×480, 640×360, 352×288, 320×240)
50Hz: 50fps@(704×576, 640×480, 640×360, 352×288, 320×240)
Tertiary Stream 60Hz: 30fps@(1920×1080, 1280×720, 704×576, 640×480, 640×360, 352×288, 320×240)
50Hz: 25fps@(1920×1080, 1280×720, 704×576, 640×480, 640×360, 352×288, 320×240)
Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Video Bit Rate 16Kbps~16Mbps(CBR/VBR Adjustable)
Privacy Masking Up to 8 Areas (Mask Area and Mosaic Area are optional)
ROI Up to 8 areas
Image Setting Brightness/Contrast/Sharpness
Network
Network Storage NAS(Support NFS, SMB/CIFS), ANR
Protocol IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL
Audio
Audio Compression G.711/AAC/G.722/G.726
Audio Sampling Rate 8/16/32/44.1/48KHz
Audio Bit Rate 16~256kbps
Two-way Audio Support
System
System Compatibility API, MQTT, HTTP, TCP, ONVIF Profile G & M & S & T
Storage Support microSD/SDHC/SDXC Card Local Storage, up to 1TB
Advanced Function BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark
SIP/VoIP Support Yes, Voice & Video-over-IP
Event Trigger Black/White List, Attributes Event, Motion Detection, Network Disconnection, External Input, Audio Alarm, etc.
Event Action FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc
General
Working Temperature -40℃~60℃
Working Humidity 0~95%(Non-condensing)
Power Supply DC 12~28V
Power Consumption Min.: 5.3W
Max.: 28.3W
Weather Proof Up to IP67-rated for Weather-resistant Performance
Surge Protection 4KV
Weight 1445.8g
2100g (With Supplement Light)
Dimensions 346mmX134mmX223mm
Warranty 3 Years (5 Years Optional)
Certifications
EMC CE-EMC (EN 55032, EN 55035), FCC (PART 15B), RCM-EMC (AS/NZS CISPR 32:2015+A1(2020))
Safety CE-LVD (EN IEC 62368-1), RCM-LVD (IEC 62368-1:2018)
Environment CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU)

* Naming Convention
R – High Frame Rate (60fps)
T – High Frame Rate (100fps)
W – Supplement Light Supported
C/E – AI Series
