| Camera |
| Name |
AI Weather-proof Mini Bullet Network Camera |
| Image Sensor |
1/2.8″ Progressive Scan CMOS |
| Min. Illumination |
Color: 0.005Lux@F1.6
B/W: 0Lux with IR on |
| WDR |
140dB Super WDR |
| Lens |
4mm/2.8mm/6mm@F1.6 |
| Mount |
M12 |
| Field of View |
H91°/D106°/V50°(4mm)
H111°/D128°/V61°(2.8mm)
H55°/D63°/V32°(6mm) |
| Shutter Time |
1/100000s~1s |
| DORI Distance |
D: 42m O: 16m R: 8.5m l: 4.5m (2.8mm)
D: 51.5m O: 20m R: 10.5m l: 5.5m (4mm)
D: 72m O: 33m R: 16.5m l: 8.5m (6mm) |
| IR Distance |
Up to 50m |
| Day/Night Mode |
Day/Night/Auto/Customize/Schedule |
| S/N |
>55dB |
| Video |
| Max. Image Resolution |
1920×1080 |
| Primary Stream |
60Hz: 90fps@(1920×1080)(Optional for T Series), 60fps@(1920×1080, 1280×960, 1280×720, 704×576)
50Hz: 90fps@(1920×1080)(Optional for T Series), 50fps@(1920×1080, 1280×960, 1280×720, 704×576) |
| Secondary Stream |
60Hz: 60fps@(704×576, 640×480, 640×360, 352×288, 320×240)
50Hz: 50fps@(704×576, 640×480, 640×360, 352×288, 320×240) |
| Tertiary Stream |
60Hz: 30fps@(1920×1080, 1280×720, 704×576, 640×480, 640×360, 320×240)
50Hz: 25fps@(1920×1080, 1280×720, 704×576, 640×480, 640×360, 320×240) |
| Video Compression |
H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Video Bit Rate |
16Kbps~16Mbps(CBR/VBR Adjustable) |
| Image |
| Privacy Masking |
Up to 8 Areas (Mask Area and Mosaic Area are optional) |
| ROI |
Up to 8 areas |
| Image Setting |
Brightness/Contrast/Saturation/Sharpness |
| Image Enhancement |
BLC, HLC, 2D DNR, 3D DNR, AGC, Defog, AWB, Deblur, Anti-flicker, Corridor Mode, LDC |
| Interface |
| Ethernet |
1*RJ45 10M/100M Ethernet Port |
| Audio I/O |
1/1 (Optional, Only for Multi-interface Version) |
| Alarm I/O |
1/1 (Optional, Only for Multi-interface Version) |
| Network |
| Network Storage |
NAS(Support NFS, SMB/CIFS), ANR |
| Protocol |
IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, LLDP, SIP, VPN, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL,TLS 1.2 |
| Audio |
| Audio Compression |
G.711/AAC/G.722/G.726 |
| Audio Sampling Rate |
8/16/32/44.1/48KHz |
| Audio Bit Rate |
16~256kbps |
| Intelligent Analytics |
| Video Analysis |
VCA 2.0: Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection,
Line Crossing, Loitering, Object Left, Object Removed |
| Face Detection&Face Attribute Recognition |
Detect and capture faces, get real-time snapshots;
The attributes include Age, Gender, Glasses, Mask and Cap;
Support Faces Privacy Mode, the detected faces in the face detection area will be mosaic automatically. |
| Object Counting & Report |
Count the number of objects crossing the line, optionally human and vehicle,
Support regional people counting for up to 4 detection areas |
| Heat Map |
The built-in statistical behavior analysis enables you to identify the busiest areas within the environment |
| Event |
| Basic Event |
Motion Detection, Tamper Detection, etc.;
Motion Detection, Tamper Detection, External Input, External Output, Audio Alarm, etc. (Multi-interface Version) |
| Exception |
Network Disconnection, IP Address Filtering, Record Failed, SD Card Full, SD Card Uninitialized, SD Card Error, No SD Card, Watermark |
| Event Action |
FTP Upload Record, SMTP Upload Record, SD Card Record, Snapshot, SIP Phone, HTTP Notification, etc.;
FTP Upload Record, SMTP Upload Record, SD Card Record, Snapshot, External Output, Play Audio, SIP Phone, HTTP Notification, etc. (Multi-interface Version) |
| System |
| Watermark |
Support |
| Storage |
Support microSD/SDHC/SDXC Card Local Storage, up to 1TB |
| SIP/VoIP Support |
Yes, Voice & Video-over-IP |
| System Compatibility |
ONVIF Profile G & M & S & T, API |
| General |
| Working Temperature |
-40℃~60℃ |
| Working Humidity |
0~95%(Non-condensing) |
| Power Supply |
PoE (802.3af); PoE (802.3af) / DC 12V±10% (Multi-interface Version) |
| Power Consumption |
Min.: 2.5W (DC 12V), 3.2W(PoE) |
| Max.: 7.3W (DC 12V), 9W(PoE) |
|
| Weight |
Approx. 750g |
| Dimensions |
Φ76mmX214.5mm |
| Warranty |
3 Years / 5 Years (Optional) |
| Certifications |
| EMC |
CE-EMC (EN 55032, EN 55035), FCC (PART 15B) |
| Safety |
CE-LVD (EN IEC 62368-1) |
| Environment |
CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU) |
| Protection |
IP67 |
