| Camera |
|---|
| Model | MS-C8477-HPG1 |
| Image Sensor | Dual 1/1.8″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.0005Lux@(F1.0, AGC ON), B/W: 0Lux with IR on |
| WDR | 140dB Super WDR |
| Lens | 4mm@F1.0 |
| Mount | M12 |
| Field of View | H180°/V58° |
| Shutter Time | 1/100000s~1s |
| DORI Distance | Detect: 62.7m Observe: 24.7m Recognize: 12.3m Identify: 6.2m |
| Light Type | 4 x IR Lights, 2 x White Lights |
| Light Distance | Up to 30m (IR Light), Up to 25m (White Light) |
| IR Wave Length | 850nm |
| Day/Night Mode | Day/Night/Auto/Customize |
| S/N | >55dB |
| Video |
|---|
| Max. Image Resolution | 5120×1520 |
| Primary Stream | 60Hz: 30fps@(5120×1520), 50Hz: 25fps@(5120×1520) |
| Secondary Stream | 60Hz: 30fps@(1280×380, 960×288, 736×224, 640×190)
50Hz: 25fps@(1280×380, 960×288, 736×224, 640×190) |
| Tertiary Stream | 60Hz: 30fps@(1920×576), 50Hz: 25fps@(1920×576) |
| ePTZ Stream | 60Hz: 30fps@(1920×1080), 50Hz: 25fps@(1920×1080) |
| Video Compression | H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Video Bit Rate | 16Kbps~16Mbps(CBR/VBR Adjustable) |
| Image |
|---|
| Privacy Masking | Up to 8 Mask Areas |
| ROI | Up to 8 Areas |
| Image Setting | Brightness/Contrast/Saturation/Sharpness |
| Image Enhancement | BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, AGC, Anti-flicker, Image Rotation, Deblur, etc. |
| Interface |
|---|
| Ethernet | 1*RJ45 10M/ 100M Ethernet Port |
| Built-in Microphone | Support |
| Audio Interface | 1*Audio Out Interface |
| Alarm I/O | 1/1 |
| Network |
|---|
| Network Storage | NAS(Support NFS, SMB/CIFS) |
| Protocol | IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS,
DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL,TLS 1.2 |
| Audio |
|---|
| Audio Compression | G.711/AAC/G.722/G.726 |
| Audio Sampling Rate | 8/16/32/44.1/48KHz |
| Audio Bit Rate | 16~256kbps |
| Intelligent Analytics |
|---|
| Video Analysis | VCA 2.0: Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection, Line Crossing, Loitering, Object Left, Object Removed |
| Object Counting & Report | Count the number of objects crossing the line, optionally human and vehicle,
Support regional people counting for up to 4 detection areas |
| Heat Map | The built-in statistical behavior analysis enables you to identify the busiest areas within the environment |
| Event |
|---|
| Basic Event | Motion Detection, Tamper Detection, Audio Alarm, External Input, External Output, etc. |
| Exception | Network Disconnection, IP Address Filtering, Record Failed, SD Card Full, SD Card Uninitialized, SD Card Error, No SD Card, Watermark,etc. |
| Event Action | FTP Upload, SMTP Upload, SD Card Record, SIP Phone, HTTP Notification, etc. |
| System |
|---|
| Storage | Support Micro SD/SDHC/SDXC Card Local Storage, up to 1TB |
| SIP/VoIP Support | Yes, Voice & Video-over-IP |
| System Compatibility | ONVIF Profile G & M & S & T, API |
| General |
|---|
| Working Temperature | -40℃~60℃ |
| Working Humidity | 0~95%(Non-condensing) |
| Power Supply | PoE (802.3at) / DC 12V / 2A±20% |
| Power Consumption | Min.: 4.2W(DC 12V), 5W(PoE)
Max.(Night Mode+H265+Full Frame+VCA on+Primary/Secondary/Tertiary Stream on+IR on+White Light on): 12.7W(DC 12V), 15W(PoE) |
| Weight | 1.5Kg |
| Dimensions | Φ160mmX128mm |
| Warranty | 3/5 Years |
| Certifications |
|---|
| EMC | CE-EMC (EN 55032, EN 55035, EN61000), FCC (PART 15B) |
| Safety | CE-LVD (EN IEC 62368-1) |
| Environment | CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU) |
| Protection | IP67, IK10 |
