| Camera |
|---|
| Image Sensor | 1/1.8″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.004Lux@F1.2
B/W: 0Lux with IR on |
| WDR | 120dB Super WDR |
| Shutter Time | 1/100000s~1s |
| Day/Night Mode | Day/Night/Auto/Customize/Schedule |
| DORI Distance | D: 98.5~212M O: 38.5~83M
R: 19~41.5M I: 9.5~20.5M |
| S/N | >55dB |
| Illuminator |
|---|
| Illuminator Number | 6 |
| IR Wave Length | 850nm |
| Illumination Distance | Up to 80m |
| Illuminator On/Off Control | Auto/Manual |
| Lens |
|---|
| Lens | Motorized 2.8mm~12mm@F1.2 |
| Field of View | H105°~46.5°/D122.5°~53.5°/V55.5°~26° |
| Mount | Φ17 |
| Focus Control | Auto/Manual |
| Close Focus Distance | W: 1m; T: 1.5m |
| Aperture | Max. F1.2 |
| Iris Type | P-Iris |
| Camera Angle Adjustment | Pan: 0°~360°, Tilt: 0°~90°, Rotation: 0°~360° |
| Video |
|---|
| Max. Image Resolution | 3840×2160 |
| Primary Stream | 60Hz: 60fps@(3840×2160, 3072×2048, 2592×1944, 2592×1520, 2048×1536, 1920×1080, 1280×960, 1280×720)
50Hz: 50fps@(3840×2160, 3072×2048, 2592×1944, 2592×1520, 2048×1536, 1920×1080, 1280×960, 1280×720) |
| Secondary Stream | 60Hz: 60fps@(704×576, 640×480, 640×360)
50Hz: 50fps@(704×576, 640×480, 640×360) |
| Tertiary Stream | 60Hz: 30fps@(1920×1080, 1280×720, 704×576, 640×480, 640×360)
50Hz: 25fps@(1920×1080, 1280×720, 704×576, 640×480, 640×360) |
| Quaternary Stream | 60Hz: 10fps@(1280*720), 30fps@(704*576, 640*480, 640*360)
50Hz: 10fps@(1280*720), 25fps@(704*576, 640*480, 640*360) |
| Video Compression | H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Video Bit Rate | 16Kbps~16Mbps(CBR/VBR Adjustable) |
| Image |
|---|
| Privacy Masking | Up to 8 Areas(Mask Area and Mosaic Area are optional) |
| ROI | Up to 8 areas |
| Image Setting | Brightness/Contrast/Saturation/Sharpness |
| Image Rotation | Rotating 180°, Flip Horizontal, Flip Vertical, Clockwise 90°, Anticlockwise 90° |
| Image Enhancement | BLC, HLC, DNR, AWB, Defog, AGC, Anti-flicker, Deblur, LDC |
| Additional Zoom | Up to 32X |
| Network |
|---|
| Network Storage | NAS (Support NFS, SMB/CIFS), ANR |
| Protocol | IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, LLDP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS1.2 |
| Interface |
|---|
| Ethernet | 1*RJ45 10M/100M Ethernet Port |
| Power Port | DC5521 |
| Audio I/O | 1/1 |
| Alarm I/O | 2/2 (Alarm Output 2: wet contact, 10mA 12V DC) |
| Audio |
|---|
| Audio Compression | G.711/AAC/G.722/G.726 |
| Audio Sampling Rate | 8/16/32/44.1/48KHz |
| Audio Bit Rate | 16~256Kbps |
| Intelligent Analytics |
|---|
| Video Analysis | VCA 2.0: Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection,
Line Crossing, Loitering, Object Left, Object Removed |
| Attribute Extraction | Simultaneously detect up to 50 targets and capture humans and vehicles in real time.
Recognize attributes including Upper and Lower Clothing Color, Hat, and Vehicle Types (Bicycle, Car, Motorcycle, Bus, Truck, E-scooter). |
| Face Detection & Face Attribute Recognition | Detect and capture faces, get real-time snapshots. The attributes include Age, Gender, Glasses, Mask and Cap. |
| Object Counting & Report | Count the number of objects crossing the line, optionally human and vehicle.
Support regional people counting for up to 4 detection areas. |
| Heat Map | The built-in statistical behavior analysis enables you to identify the busiest areas within the environment |
| Helmet Detection | Detects whether individuals are wearing safety helmets. Triggers an alarm when a person is identified without a helmet, enhancing safety compliance on-site. |
| Event |
|---|
| One-Click Disarm | Support |
| Basic Event | Motion Detection, Tamper Detection, Audio Alarm, External Input, External Output, etc. |
| Exception | Network Disconnection, IP Address Conflict, Record Failed, SD Card Full, SD Card Uninitialized, SD Card Error, No SD Card, etc. |
| Event Action | FTP Upload, Snapshot, SMTP Upload, SD Card Record, External Output, Play Audio, SIP Phone, HTTP Notification, etc. |
| System |
|---|
| Storage | Support microSD/SDHC/SDXC Card Local Storage, up to 1TB |
| TPM 2.0 | Support |
| Watermark | Support |
| SIP/VoIP Support | Yes, Voice & Video-over-IP |
| System Compatibility | ONVIF Profile G & M & S & T, API |
| VMS Support | Nx witness, Milestone XProtect, Genetec Security Center, Digifort VMS, AXXON One, Arteco uSee, Arteco Omnia, 3dEYE Video Portal, Camcloud Cloud Video Surveillance, Salient CompleteView VMS, CathexisVision, Mirasys VMS, Digiever CMS, Watchful OS etc. |
| Edge |
|---|
| Edge Storage | Support microSD Card Local Storage, up to 1TB (UHS-I Micro SD, A2 standard or above);
Support SD Card Health Information Query |
| Edge VMS | Single Camera Mode: Support to register the maximum number of the camera – up to 1 camera (purchase the license with 1× NX channel) – total bandwidth: Up to 11Mbps.
Multi-camera Mode: Support to register the maximum number of the camera – up to 4 cameras (purchase the license with 4× NX channel) – total bandwidth: Up to 11Mbps.
*Al Mode can be enabled for both 1 and 4 camera setups. However, for external connections, only basic video streams are supported, and metadata is not supported. |
| NX Merge | Max. 16 Cameras |
| General |
|---|
| Working Temperature | -40℃~60℃ |
| Working Humidity | 0~95% RH (Non-condensing) |
| CPU | Dual-core 64-bit Arm CA53 processor |
| Memory | 2GB RAM, 4GB Flash |
| Power Supply | PoE+ (802.3at) / DC 10V~DC 28V
(Note: When both the power adapter and PoE are connected, please disconnect either one. This will not cause the device to restart; it will continue to work normally.) |
| Power Consumption | Min.: 4W (DC), 4.5W (PoE+)
Max.: 15.5W (DC), 17.5W (PoE+) |
| Surge Protection | 6KV |
| Net Weight | 1600g |
| Gross Weight | 2400g |
| Dimensions | 301mm X 108mm X 126mm |
| Warranty | 3/5 Years |
| Certification |
|---|
| EMC | CE-EMC (EN 55032, EN 55035), FCC (PART 15B) |
| Safety | UL: UL 62368-1, CE-LVD (EN IEC 62368-1) |
| Environment | CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU) |
| Protection | IP67, IK10 |
