AETEK Outdoor 8-Port Managed PoE Switch Hub-of-Pole for Long-Distance Surveillance

H60-084-30-250-V2

  • 8 x 30W 802.3at PoE Ports
  • 4 x SFP Fiber Uplinks
  • L2 PRO Managed with NTS Software
  • 250W Total Power Budget
  • IP67/IK10 Cast Aluminum
  • 6KV PoE + 40KV AC Surge Protection
  • Operating Range: -40°C to 65°C
  • Quad-SFP for Ring Topology

Description

Hub-of-Pole for Campus-Scale CCTV

The H60-084-30-250-V2 is built for outdoor aggregation: 8 PoE ports for downstream cameras, plus 4 SFP slots for upstream fiber redundancy and ring topologies. It is the ideal hub for campus-scale projects where multiple camera clusters feed a single fiber backbone.

Four SFP Slots Enable Resilient Ring

Most outdoor switches offer only 2 SFP slots, forcing a star topology. With 4 SFP slots, the H60-084 supports redundant ring topologies (RSTP/MSTP) for sub-second failover – essential for critical infrastructure across Saudi mega-projects.

Same Hardened Build, More Capacity

Like the rest of the H60 series, this switch is housed in IP67/IK10 cast aluminum with 6KV PoE and 40KV AC surge protection. -40°C to 65°C operation handles desert and elevated terrain conditions across the Kingdom.

Specification

Specification Value
Series H60 Outdoor L2 PRO Managed Switch
PoE Ports 8 x 30W 802.3at PoE
Uplink Ports 4 x SFP Fiber
Total Power Budget 250W
Management L2 PRO Managed + NTS Software
Enclosure IP67 / IK10 Cast Aluminum
Surge Protection 6KV PoE / 40KV AC
Operating Temperature -40°C to 65°C
