AETEK Ceiling PoE Switch with Daisy-Chain Reduce Cabling Costs in Long Corridors

C62-050-30-B

  • Patented Ceiling-Mount Design
  • 1 x GbE bt PD PoE Input
  • 1 x GbE bt PoE + 4 x GbE at PoE PSE Outputs
  • Daisy-Chain Support – Reduce Cabling
  • 12V / 24V DC Output for Non-PoE Devices
  • Ideal for Long Corridors and Hotels
  • Snap-On Premium Finish
  • Up to 50% Reduction in Installation Cost

Description

Daisy-Chain Topology Slashes Cabling Cost

The C62-050-30-B’s daisy-chain support allows multiple ceiling switches to be linked in series rather than each being individually home-run back to the core. For hotel corridors, hospital wards and long retail aisles in Saudi Arabia, this can cut total cabling cost by 30–50%.

Direct DC Output Powers Door Locks and Sensors

Beyond standard PoE, the switch provides 12V and 24V DC outputs that directly power non-PoE devices like access control readers, electric locks, door sensors and IoT modules – removing the need for separate power supplies.

Hotels, Healthcare, Office Corridors

Combine premium aesthetics with cost-effective installation. The C62 series is the AETEK flagship ceiling solution for Saudi Arabia’s growing hospitality and healthcare sectors – where ceiling visibility and installation speed both matter.

Specification

Specification Value
Series C62 Ceiling PoE Switch
PoE Input 1 x GbE 802.3bt PD Input
PoE Output 1 x GbE bt + 4 x GbE at PoE PSE
DC Output 12V / 24V DC
Special Feature Daisy-Chain Support
Switch Type Unmanaged
Mounting Patented Ceiling Latch-Bolt
Application Hotels, Healthcare, Long Corridors
