AETEK Outdoor 4-Port Managed PoE Switch The Workhorse Outdoor Managed Node

H60-044-30-150-V2

  • 4 x 30W 802.3at PoE Ports
  • 2 x SFP + 2 x RJ45 Uplinks
  • L2 PRO Managed with NTS Software
  • 150W Total Power Budget
  • IP67/IK10 Cast Aluminum
  • 6KV PoE + 40KV AC Surge Protection
  • Operating Range: -40°C to 65°C
  • Ideal for IP CCTV Projects

Description

The Most Common Outdoor Managed Node

The H60-044-30-150-V2 is the default specification for IP CCTV projects across Saudi Arabia. Four 30W PoE ports cover standard fixed cameras and domes, dual SFP slots enable fiber backhaul, and dual RJ45 copper uplinks add deployment flexibility.

Managed Visibility Reduces Site Visits

L2 PRO management with built-in NTS topology lets head-end operators see which cameras are online, diagnose cable faults remotely, monitor PoE consumption per port and reboot devices over the network – saving costly truck rolls to remote sites.

Government-Grade Surge Protection

40KV AC surge protection paired with 6KV PoE-line surge protection meets the resilience requirements of government, defense and utility projects. The IP67/IK10 cast aluminum housing handles dust, sand and impact.



Specification

Specification Value
Series H60 Outdoor L2 PRO Managed Switch
PoE Ports 4 x 30W 802.3at PoE
Uplink Ports 2 x SFP + 2 x RJ45
Total Power Budget 150W
Management L2 PRO Managed + NTS Software
Enclosure IP67 / IK10 Cast Aluminum
Surge Protection 6KV PoE / 40KV AC
Operating Temperature -40°C to 65°C
